New Gigabyte Intel Xeon E5-2400 and Xeon E5-2600 Barebones

Gigabyte recently released new barebones systems for the new Intel Xeon E5-2400 and Intel Xeon E5-2600 series CPUs. Barebones systems are popular with resellers and end users because the chassis, motherboard, and power supplies are generally optimized for the package. Further, cabling generally comes pre-installed so usually taking a barebones system to a production ready system can be as simple as adding CPUs, RAM and drives. Gigabyte is a very familiar name in the consumer space, but they have been making a push into the consumer and high-end workstation markets. Below is an overview of the new systems that Gigabyte recently launched for Intel Xeon E5-2400 and Intel Xeon E5-2600 series CPUs.

High Density Solutions:

•  GS-R22PD:
  • 2U rack system containing 4 dual socket motherboards mounted in drawers accessible from the rear of the chassis
  • Intel Xeon E5-2400 platform
  • 48 x DIMM slots
  • 12 x 3.5″ or 16 x 2.5″ hot-swappable HDD bays
  • Up to 4 GPUs (supports PCIe Gen 3.0)
•  GS-R22PDC:
  • 2U rack system containing 4 dual socket motherboards mounted in drawers accessible from the front of the chassis
  • Intel Xeon E5-2400 platform
  • 48 x DIMM slots
  • 16 x 2.5″ hot-swappable HDD bays
  • Up to 4 GPUs (supports PCIe Gen 3.0)

Extreme Performance Computing Solutions:

•  GS-R12P4P:
  • 1U dual socket rack system
  • Intel Xeon E5-2600 platform
  • 16 x DIMM slots
  • High end dual GbE LAN controller
  • Supports SAS 2.0 6Gb/s
•  GS-R12PE/GS-R12PE1:
  • 1U dual socket rack system
  • Intel Xeon E5-2600 platform
  • 24 x DIMM slots
  • 10GbE BASE-T LAN + High end dual GbE LAN controllers
  • Supports SAS 2.0 6Gb/s
  • Redundant 80 PLUS Platinum or Gold power supplies
•  GS-R22PXP:
  • 2U dual socket rack system
  • Intel Xeon E5-2600 platform
  • 16 x DIMM slots
  • High end dual GbE LAN controller
  • Supports SAS 2.0 6Gb/s
  • 12 x 3.5” hot-swappable HDD bays
  • 5 x PCIe connectors
  • Redundant power supply
•  GS-R22PE/GS-R22PE1:
  • 2U dual socket rack system
  • Intel Xeon E5-2600 platform
  • 24 x DIMM slots
  • 10GbE BASE-T LAN + High end dual GbE LAN controllers
  • Supports SAS 2.0 6Gb/s
  • 12 x 3.5” hot-swappable + 4 x 2.5” fixed HDD bays
  • Redundant 80 PLUS Platinum or Gold power supplies

Mass Storage Solutions:

•  GS-R22PXL:
  • 2U dual socket rack system
  • Intel Xeon E5-2400 platform
  • 12 x DIMM slots
  • 12 x 3.5” hot-swappable HDD bays
  • Supports SAS 2.0 6Gb/s
  • 5 x PCIe connectors
•  GS-R22PFL:
  • 2U dual socket rack system
  • Intel Xeon E5-2400 platform
  • 12 x DIMM slots
  • 24 x 2.5” hot-swappable HDD bays
  • Supports SAS 2.0 6Gb/s
  • 5 x PCIe connectors

Energy Efficient General Purpose Solutions:

•  GS-R12P4S:
  • 1U dual socket rack system
  • Intel Xeon E5-2400 platform
  • 8 x DIMM slots
  • 1 x PCIe x16 (Gen 3.0 x16)
•  GS-R12P4E:
  • 1U dual socket rack system
  • Intel Xeon E5-2400 platform
  • 12 x DIMM slots
  • High end dual GbE LAN controller
  • Optimized chassis airflow
  • 1 x PCIe x16 (Gen 3.0 x8)
  • 1 x PCIe x8 (Gen 3.0 x8)
•  GS-R12P8E:
  • 1U dual socket rack system
  • Intel Xeon E5-2400 platform
  • 12 x DIMM slots
  • High end dual GbE LAN controller
  • 8 x 2.5” hot-swappable HDD bays
  • Optimized chassis airflow
  • 1 x PCIe x16 (Gen 3.0 x8)
  • 1 x PCIe x8 (Gen 3.0 x8)

More details can be found on GIGABYTE’s website by clicking here.
