Intel Celeron J6413 Powered 6x i226 2.5GbE Fanless Firewall Power Consumption
This unit comes with the LiteOn 12V power supply that performs better than other generic brands. We have seen this 48W power supply with a few different units now, and it is better than the generic “Replacement A/C adapter” many of these came with previously.
The J6413 is generally a lower-power device, with less than 12W at idle. Single-threaded we get to around 14-15W. We saw highs in the 19-21W range under heavier multi-threaded workloads.
If you want to see more on the power testing, we show the unit powered on with a power meter in the video.
Key Lessons Learned
The build quality of this unit seems to be quite good. One challenge some may have is that it is using one of the larger passively cooled cases.
Given the choice of a larger chassis or a system that overheats, we will take the larger chassis.
On the software side, Proxmox VE installed without issue, but we could not get the VT-d NIC pass-through working on this unit.
In the video, we also discuss that OpenWRT installed and OPNsense 22.7 installed as well. OPNsense actually came pre-installed since pfSense 2.6 does not support the Intel i226 NIC. That is a pfSense 2.7 feature, so one has to use either a pfSense 2.7 snapshot or wait for that to release if pfSense Plus is not being used.
All told, we think that the N5105 is probably a better value. This is a nice unit, but the J6413 was not benchmarking faster than the N5105, likely because of the lack of L3 cache. When the N5105 units first came out, they used more power and cost more, but were much faster than the J4125. With the J6413, we get similar levels of performance, power, and cost to the N5105, and sometimes the N5105 units are less expensive.
Final Words
Two years ago, a quad-core 6x 2.5GbE NIC machine like this would have been astounding. Now, we have seen so many of these that there are items that give us pause. A great example of that is the mSATA SSD instead of a standard M.2 SSD.
Still, the Intel Celeron J6413 performed reasonably well, and this came with the chassis that we prefer keeping temps cool throughout our testing. As great as something like the R86S is, it is also nice to have a passively cooled unit.
Overall, this unit checked a lot of boxes and worked reasonably well. It just leaves us wanting something a little bit more since there was a transition to a new CPU with the J6413. We want something lower power, lower cost, or something to help us recommend this over a N5105 unit. The cost side may change in the future, but we are probably still going to buy N5105 units in the near term.
